product description:

This product provides an effective implementation tool for logistics monitoring applications in various industries. XK04T can put the packaging and packaging materials, related product code, production and serial number information, shipping information, and sales channels and other information in the form of text, passwords and bar codes printed on the packaging of the outer box to facilitate the entire transportation and distribution processes In tracking. Through the special process control software and communication arrangement, as well as the specially designed packaging process, it can also help customers to achieve the purpose of the association between the inner and outer packaging codes and greatly improve the reliability and rigor of the distribution channel monitoring and anti-serialization applications. Equipped with suitable material moving device, it can directly print the production materials on high-precision products such as electronic components and circuit boards, greatly improving the manufacture of computer components, production efficiency and product traceability. Zebra PAX heat transfer printing engine as the core technology, together with the industrial computer and special software to control the program, the operation of natural fast, clear display, suggesting rich.

specification:

machine type	XK-04T
Power / Power	220V 50/60HZ 0.45KW
working pressure	0.5-0.7Mpa、 300L/min
Labeling speed	Up to 80 / min (with the stickers, label size, labeling methods)
Labeling accuracy	±0.5mm(Excluding package and label errors)
Labeling direction	Top paste, side stickers, corner stickers
Resolution	Available in 203, 300 and 600 dpi options
printing speed	305mm/sec.（203dpi）、 203mm/sec.（300dpi）
Label size (print)	Standard type: width 114mm, length 13-104mm (203 / 300dpi); length 13-81mm (600dpi) Enhanced type: width 180mm, length 76-168mm
Label size (labeling)	Pneumatic labeling: the smallest (W) 15 × (L) 20mm; all labeling: the largest (W) 168 × (L) 152mm
Label specifications	Must use the "Gela Xin" shading, the thickness of the paper: 5 microns surface hardness consistent with Star Kun recognition standards
Communication port / control port	Standard RS232 or RS485 / Reserved
Use environment	Temperature 5-40 ° C Relative 20-90%
Machine size / weight	1000×850×1900mm 100kg
